Spatial Analysis of the Soil Carbon Sequestration Potential of Crop-residue Return in China Based on Model Simulation

doi:10.5814/j.issn.1674-764X.2019.02.009

Abstract

Abstract:

Crop-residue return is a recommended practice for soil and nutrient management and is important in soil organic carbon (SOC) sequestration and CO₂ mitigation. We applied a process-based Environmental Policy Integrated Climate (EPIC) model to simulate the spatial pattern of topsoil organic carbon changes from 2001 to 2010 under 4 crop-residue return scenarios in China. The carbon loss (28.89 Tg yr^-1) with all crop-residue removal (CR0%) was partly reduced by 22.38 Tg C yr^-1under the status quo CR30% (30% of crop-residue return). The topsoil in cropland of China would become a net carbon sink if the crop-residue return rate was increased from 30% to 50%, or even 75%. The national SOC sequestration potential of cropland was estimated to be 25.53 Tg C yr^-1 in CR50% and 52.85 Tg C yr^-1 in CR75%, but with high spatial variability across regions. The highest rate of SOC sequestration potential in density occurred in Northwest and North China while the lowest was in East China. Croplands in North China tended to have stronger regional SOC sequestration potential in storage. During the decade, the reduced CO₂ emissions from enhanced topsoil carbon in CR50% and CR75% were equivalent to 1.4% and 2.9% of the total CO₂ emissions from fossil fuels and cement production in China, respectively. In conclusion, we recommend encouraging farmers to return crop-residue instead of burning in order to improve soil properties and alleviate atmospheric CO₂ rises, especially in North China.

Key words: cropland, crop-residue return, soil carbon sequestration, spatial pattern, EPIC model

CHEN Jinghua,WANG Shaoqiang,Florian KRAXNER,Juraj BALKOVIC,XU Xiyan,SUN Leigang. Spatial Analysis of the Soil Carbon Sequestration Potential of Crop-residue Return in China Based on Model Simulation[J]. Journal of Resources and Ecology, 2019, 10(2): 184-195.

Figures/Tables 13

References 33

[34]	Lou Y, Xu M, Wang W, et al.2011. Return rate of straw residue affects soil organic C sequestration by chemical fertilization. Soil and Tillage Research, 113: 70-73, doi:10.1016/j.still.2011.01.007.
[35]	Lu F, Wang X, Han B, et al.2009. Soil carbon sequestrations by nitrogen fertilizer application, straw return and no-tillage in China’s cropland.Global Change Biology, 15: 281-305, doi: 10.1111/j.1365-2486.2008. 01743.x.
[36]	Lu F, Wang X, Han B, et al.2010. Net mitigation potential of straw return to Chinese cropland: estimation with a full greenhouse gas budget model.Ecological Applications, 20(3): 634-647.
[37]	Lu F.2015. How can straw incorporation management impact on soil carbon storage? A meta-analysis.Mitigation and Adaptation Strategies for Global Change, 20: 1545-1568, doi:10.1007/s11027-014-9564-5.
[38]	Lun F, Canadell J G, He L, et al.2016. Estimating cropland carbon mitigation potentials in China affected by three improved cropland practices.Journal of Mountain Science, 13(10): 1840-1854.
[39]	Mei F, Wu X, Yao C, et al.1988. Rice cropping regionalization in China.Chinese Journal of Rice Science, 2(3): 97-110. (in Chinese)
[40]	NBSPRC (National Bureau of Statistics of the People’s Republic of China). China Rural Statistical Yearbook 2001/2002/2003/2004/2005/2006/ 2007/2008/2009/2010. Beijing: China Statistics Press. (in Chinese)
[41]	Palmer P I, Jacob D J, Jones D, et al.2003. Inverting for emissions of carbon monoxide from Asia using aircraft observations over the western Pacific. Journal of Geophysical Research, 108(D21): 8828, doi:10.1029/2003JD003397.
[42]	Pan G, Xu X, Smith P, et al.2010. An increase in topsoil SOC stock of China's croplands between 1985 and 2006 revealed by soil monitoring.Agriculture, Ecosystems and Environment, 136: 133-138, doi:10.1016/ j.agee.2009.12.011.
[43]	Paustian K, Cole C V, Sauerbeck D, et al.1998. CO2 mitigation by agriculture: on review. Climate Change, 40(1): 135-162.
[44]	Pétron G, Granier C, Khattatov B, et al.2004. Monthly CO surface sources inventory based on the 2000-2001 MOPITT satellite data.Geophysical Research Letters, 31: L21107, doi:10.1029/2004GL020560.
[45]	Piao S, Fang J, Ciais P, et al.2009. The carbon balance of terrestrial ecosystems in China. Nature, 458: 1009-1014, doi:10.1038/nature07944.
[46]	Qin Z, Huang Y, Zhuang Q.2013. Soil organic carbon sequestration potential of cropland in China.Global Biogeochemical Cycles, 27: 711-722, doi:10.1002/gbc.20068.
[47]	Rasmussen P E, Albrecht S L, Smiley R W.1998. Soil C and N changes under tillage and cropping systems in semi-arid Pacific Northwest agriculture.Soil and Tillage Research, 47: 197-205.
[48]	Rasmussen P E, Allmaras R R, Rohde C R, et al.1980. Crop residue influences on soil carbon and nitrogen in a wheat-fallow system.Soil Science Society of America Journal, 44(3): 596-600, doi:10.2136/sssaj1980.03615995004400030033x.
[49]	Shi X Z, Yu D S, Pan X Z, et al.2002. A framework for the 1:1,000,000 soil database of China. Paper presented at 17th World Congress of Soil Science for Soil and Fertilizer Society of Thailand, Bangkok, Thailand, August 14-21.
[50]	Smith P, Poelson D S, Glendining M J, et al.1998. Preliminary estimates of the potential for carbon mitigation in European soils through no-till farming. Global Change Biology, 4: 679-685.
[51]	Smith P, Smith J U, Powlson D S, et al.1997. A comparison of the performance of nine soil organic matter models using datasets from seven long-term experiments. Geoderma, 81: 153-225, doi:10.1016/S0016-7061(97)00087-6.
[1]	Balkovic J, van der Velde M, Schmid E, et al.2013. Pan-European crop modelling with EPIC: Implementation, up-scaling and regional crop yield validation.Agricultural Systems, 120: 61-75, doi:10.1016/j.agsy.2013.05.008.
[2]	Balkovic J, van der Velde M, Skalsky R, et al.2014. Global wheat production potentials and management flexibility under the representative concentration pathways.Global and Planetary Change, 122: 107-121, doi:10.1016/j.gloplacha.2014.08.010.
[52]	STEMOA, 2010. Survey and access report of national crop straw source. Department of Science and Technology and Education, Ministry of Agriculture of the People’s Republic of China. .
[53]	Stewart C E, Paustian K, Conant R T, et al.2007. Soil carbon saturation: Concept, evidence and evaluation.Biogeochemistry, 86(1): 19-31.
[3]	Boden T A, Marland G, Andres R J.2016. Global, Regional, and National Fossil-Fuel CO2 Emissions. Carbon Dioxide Information Analysis Center, Oak Ridge National Laboratory, U.S. Department of Energy, Oak Ridge, Tenn., U.S.A,doi: 10.3334/CDIAC/00001_V2016.
[4]	Cao G L, Zhang X Y, Wang Y Q, et al.2008. Estimation of emissions from field burning of crop straw in China.Chinese Science Bulletin, 53(5): 784-790, doi:10.1007/s11434-008-0145-4.
[5]	Cao G L, Zhang X Y, Zheng F C.2006. Inventory of black carbon and organic carbon emissions from China.Atmospheric Environment, 40: 6516-6527, doi:10.1016/j.atmosenv.2006.05.070.
[6]	CAREI.2000. Strategic considerations for development and utilization of biological energy in China. Chinese Association for Rural Energy Industries. Beijing, 61pp. (in Chinese)
[54]	Streets D G, Yarber K F, Woo J H, et al.2003. Biomass burning in Asia: Annual and seasonal estimates and atmospheric emissions. Global Biogeochemical Cycles, 17(4): 1099, doi:10.1029/2003GB002040.
[55]	Sun W, Huang Y, Zhang W, et al.2010. Carbon sequestration and its potential in agricultural soils of China. Global Biogeochemical Cycles, 24: GB3001, doi:10.1029/2009GB003484.
[7]	Ciais P, Sabine C, Bala G, et al.2013. Carbon and Other Biogeochemical Cycles. In: Climate Change 2013: The Physical Science Basis. Contribution of Working Group I to the Fifth Assessment Report of the Intergovernmental Panel on Climate Change. Stocker T F, Qin D, Plattner G K, et al. Cambridge University Press, Cambridge, United Kingdom and New York, NY, USA.
[8]	Cui M, Zhao L, Tian Y, et al.2008. Analysis and evaluation on energy utilization of main crop straw resources in China.Transactions of the CSAE, 24(12): 291-296. (in Chinese)
[56]	Tang H, Qiu J, Ranst E V, et al.2006. Estimations of soil organic carbon storage in cropland of China based on DNDC model. Geoderma, 134: 200-206.
[57]	The State Council of the People’s Republic of China. 2012. Circular of the State Council on Printing and Distributing the National Modern Agricultural Development Plan (2011-2015). .
[9]	Duiker S W, Lal R.1999. Crop residue and tillage effects on carbon sequestration in a Luvisol in central Ohio.Soil and Tillage Research, 52: 73-81,doi:10.1016/S0167-1987(99)00059-8.
[10]	Elshout P M F, van Zelm R, Balkovic J, et al.2015. Greenhouse-gas payback times for crop-based biofuels.Nature Climate Change, 5: 604-611, doi:10.1038/NCLIMATE2642.
[58]	van der Velde M, Bouraoui F, Aloe A.2009. Pan-European regional-scale modelling of water and N efficiencies of rapeseed cultivation for biodiesel production.Global Change Biology, 15: 24-37, doi:10.1111/j.1365-2486.2008.01706.x.
[59]	Wang J, Wang X, Xu M, et al.2015. Crop yield and soil organic matter after long-term straw return to soil in C. Nutrient Cycling in Agroecosystems, 102: 371-381, doi:10.1007/s10705-015-9710-9.
[11]	FAO. 2014. Food and Agricultural Organization of the United Nations.
[12]	Follett R F.2001. Soil management concepts and carbon sequestration in cropland soils.Soil and Tillage Research, 61(1): 77-92.
[60]	Wang S, Huang M, Shao X, et al.2004. Vertical distribution of soil organic carbon in China. Environmental Management, 33: S200-S209, doi:10.1007/s00267-003-9130-5.
[61]	Wang S, Zhou C, Li K, et al.2001. Estimation of soil organic carbon reservoir in China. Journal of Geographical Sciences, 11(1): 3-13.
[13]	Han B, Wang X K, Lu F, et al.2008. Soil carbon sequestration and its potential by cropland ecosystems in China.Acta Ecologica Sinica, 28(2): 612-619. (in Chinese)
[14]	Han P F, Zhang W, Wang G C, et al.2016. Changes in soil organic carbon in croplands subjected to fertilizer management: a global meta-analysis.Scientific Reports, 6: 27199, doi: 10.1038/srep27199.
[62]	West T, Six J.2007. Considering the influence of sequestration duration and carbon saturation on estimates of soil carbon capacity.Climate Change, 80(1): 25-41.
[63]	Williams J R, Jones C A, Dyke P T.1984. A modeling approach to determining the relationship between erosion and soil productivity.Transaction of the ASAE, 27(1): 129-144.
[15]	Huang Y, Sun W J.2006. Changes in topsoil organic carbon of croplands in mainland China over the last two decades.Chinese Science Bulletin, 51(15): 1785-1803, doi: 10.1007/s11434-006-2056-6.
[16]	Hutchinson M F.2004. ANUSPLIN Version 4.3 user guide. Centre for Resources and Environmental Studies. Canberra: Australian National University.
[64]	Yan H, Cao M, Liu J, et al.2007. Potential and sustainability for carbon sequestration with improved soil management in agricultural soils of China.Agriculture, Ecosystems and Environment, 121: 325-335.
[65]	Yan X, Ohara T, Akimoto H.2006. Bottom-up estimate of biomass burning in mainland China.Atmospheric Environment, 40: 5262-5273, doi:10.1016/j.atmosenv.2006.04.040.
[17]	Izaurralde R C, Rosenberg N J, Brown R A, et al.2003. Integrated assessment of Hadley Center (HadCM2) climate-change impacts on agricultural productivity and irrigation water supply in the conterminous United States - Part II. Regional agricultural production in 2030 and 2095.Agricultural and Forest Meteorology, 117: 97-122, doi:10.1016/S0168-1923(03)00024-8.
[18]	Izaurralde R C, Williams J R, McGill W B, et al.2006. Simulating soil C dynamics with EPIC: Model description and testing against long-term data.Ecological Modelling, 192: 362-384, doi:10.1016/j.ecolmodel.2005.07.010.
[66]	Yang B, Xiong Z, Wang J, et al.2015. Mitigating net global warming potential and greenhouse gas intensities by substituting chemical nitrogen fertilizers with organic fertilization strategies in rice-wheat annual rotation systems in China: A 3-year field experiment.Ecological Engineering, 81: 289-297, doi:10.1016/j.ecoleng.2015.04.071.
[67]	Yu Y, Huang Y, Zhang W.2012. Modeling soil organic carbon change in croplands of China, 1980-2009. Global and Planetary Change, 82-83: 115-128, doi:10.1016/j.gloplacha.2011.12.005.
[19]	Lal R.2000. World cropland soils as a source or sink for atmospheric carbon.Advances in Agronomy, 71: 145-191.
[20]	Lal R.2002. Soil carbon sequestration in China through agricultural intensification and restoration of degraded and desertified ecosystems.Land Degradation & Development, 13: 469-478.
[68]	Zhang H, Ye X, Cheng T, et al.2008. A laboratory study of agricultural crop residue combustion in China: Emission factors and emission inventory.Atmospheric Environment, 42: 8432-8441, doi:10.1016/j.atmosenv.2008.08.015.
[69]	Zhao J, Zhang G, Yang D.2011. Estimation of carbon emission from burning of grain crop residues in China.Journal of Agro-Environment Science, 30(4): 812-816. (in Chinese)
[21]	Lal R.2004a. Soil carbon sequestration to mitigate climate change.Geoderma, 123: 1-22, doi:10.1016/j.geoderma.2004.01.032.
[22]	Lal R.2004b. Soil carbon sequestration impacts on global climate change and food security.Science, 304(5677): 1623-1627.
[23]	Larson W E, Clapp C E, Pierre W H, et al.1972. Effects of increasing amounts of organic residues on continuous corn: II. Organic carbon, nitrogen, phosphorus, and sulfur.Agronomy Journal, 64(2): 204-209, doi:10.2134/agronj1972.00021962006400020023x.
[24]	Le Quéré C, Andrew R M, Canadell J G, et al.2016. Global Carbon Budget 2016, Earth Syst. Sci. Data, 8: 605-649, doi: 10.5194/essd-8-605-2016. .
[70]	Zhao W, Hu Z M, Li S G, et al.2017. Impact of land use conversion on soil organic carbon stocks in an agro-pastoral ecotone of Inner Mongolia.Journal of Geographical Sciences, 27(8): 999-1010, doi: 10.1007/s11442-017-1417-1.
[71]	Zhao X, Hu K, Stahr K.2013. Simulation of SOC content and storage under different irrigation, fertilization and tillage conditions using EPIC model in the North China Plain.Soil and Tillage Research, 130, 128-135, doi:10.1016/j.still.2013.02.005.
[25]	Li C, Frolking S, Butterbach-Bahl K.2005. Carbon sequestration in arable soils is likely to increase nitrous oxide emissions, offsetting reductions in climate radiative forcing.Climatic Change, 72: 321-338.
[26]	Lin F Y, Wu Y J, Wang S Q, et al.2013. Simulation and Prediction of Straw Return on Soil Carbon Sequestration Potential of Cropland in Jiangxi Province. [J]ournal of Natural Resources, 28(6): 981-993. doi: 10.11849/zrzyxb.2013.06.009. (in Chinese)
[27]	Liu H, Jiang G M, Zhuang H Y, et al.2008. Distribution, utilization structure and potential of biomass resources in rural China: With special references of crop residues.Renewable and Sustainable Energy Reviews, 12: 1402-1418, doi:10.1016/j.rser.2007.01.011.
[28]	Liu J G, Folbert C, Yang H, et al.2013. A global and spatially explicit assessment of climate change impacts on crop production and consumptive water use.PLoS One, 8(2): e57750.
[29]	Liu J G, Williams J R, Zehnder A J B, et al.2007. GEPIC-modelling wheat yield and crop water productivity with high resolution on a global scale.Agricultural Systems, 94: 478-493, doi:10.1016/j.agsy.2006.11.019.
[30]	Liu J Y, Liu M, Zhuang D, et al.2003. Study on spatial patterns of land use change in China during 1995-2000.Science in China Series D Earth Sciences, 46(4): 373-384.
[31]	Liu J Y, Tian H Q, Liu M, et al.2005. China’s changing landscape during the 1990s: large-scale land transformation estimated with satellite data.Geophysical Research Letters, 32: L02405, doi:10.1029/2004GL021649.
[32]	Liu Q H, Shi X Z, Weindorf D C, et al.2006.Soil organic carbon storage of paddy soils in China using the 1: 1,000,000 soil database and their implications for C sequestration. Global Biogeochemical Cycles, 20(3): GB3024. doi:10.1029/2006GB002731.
[33]	Liu W, Wang C, Mol A P J, et al.2012. Rural residential CO2 emissions in China: Where is the major mitigation potential?Energy Policy, 51: 223-232, doi:10.1016/j.enpol.2012.05.045.

Parameter	Wheat		Corn		Rice
Parameter	Default value	Optimized value	Default value	Optimized value	Default value	Optimized value
HI	0.45	0.47	0.5	0.55	0.2	0.5
DMLA	6	-	6	7	6	-
DLAI	0.6	0.5	0.8	0.6	0.8	0.9
HMX (m)	1	-	2	2.5	0.8	-
RDMX (m)	2	-	2	2.5	2	-
WYSF	0.21	0.2	0.4	-	0.25	-

Parameter	Wheat		Corn		Rice
Parameter	Default value	Optimized value	Default value	Optimized value	Default value	Optimized value
HI	0.45	0.47	0.5	0.55	0.2	0.5
DMLA	6	-	6	7	6	-
DLAI	0.6	0.5	0.8	0.6	0.8	0.9
HMX (m)	1	-	2	2.5	0.8	-
RDMX (m)	2	-	2	2.5	2	-
WYSF	0.21	0.2	0.4	-	0.25	-

Item	Date
Item	Wheat-corn rotation	Double-cropping rice
Build furrow dikes	-	20-Apr
Cultivate	-	25-Apr
Plant	24-Oct (wheat)	25-Apr
Irrigate	13-Mar	2-May
Apply pesticide	25-Mar	20-May
Harvest	15-Jun	10-Jul
Cultivate	-	31-Jul
Plant	27-Jun (corn)	1-Aug
Apply pesticide	18-Jul	20-Aug
Harvest	2-Oct	5-Nov

Item	Date
Item	Wheat-corn rotation	Double-cropping rice
Build furrow dikes	-	20-Apr
Cultivate	-	25-Apr
Plant	24-Oct (wheat)	25-Apr
Irrigate	13-Mar	2-May
Apply pesticide	25-Mar	20-May
Harvest	15-Jun	10-Jul
Cultivate	-	31-Jul
Plant	27-Jun (corn)	1-Aug
Apply pesticide	18-Jul	20-Aug
Harvest	2-Oct	5-Nov

Year	Total crop-residue (TCR, Mt)			Cultivated area (A, Mha)			Yield of crop-residue (CR, t ha^-1)
Year	Wheat	Corn	Rice	Wheat	Corn	Rice	Dryland	Paddy field
2000	136.10	211.99	117.07	26.65	23.06	29.96	7.00	3.91
2001	128.23	228.18	110.63	24.66	24.28	28.81	7.28	3.84
2002	123.34	242.62	108.74	23.91	24.63	28.20	7.54	3.86
2003	118.14	231.66	100.09	22.00	24.07	26.51	7.59	3.78
2004	125.62	260.68	111.59	21.63	25.45	28.38	8.21	3.93
2005	133.13	278.76	112.87	22.79	26.36	28.85	8.38	3.91
2006	147.45	303.27	113.58	23.61	28.46	28.94	8.65	3.92
2007	149.31	304.60	115.90	23.72	29.48	28.92	8.53	4.01
2008	153.63	331.83	119.55	23.62	29.86	29.24	9.08	4.09
2009	156.88	327.71	121.79	24.29	31.18	29.63	8.74	4.11
