Projections of the Emission Reductions of Carbon Dioxide and Conventional Pollutants in the Major Transport Sectors of the Beijing-Tianjin-Hebei Region, China

doi:10.5814/j.issn.1674-764x.2023.02.015

Abstract

Abstract:

Many stakeholders recognize that the transport sector should be a major focus for reducing the emissions of carbon and air pollutants since it is the third largest sector for energy consumption in China. This study analyzed and projected the energy consumption and emissions of CO₂ and conventional air pollutants (CO, NO_X, SO₂, and PM_2.5) from four transport sectors (highway, waterway, railway and aviation) based on the LEAP model, compared the emission reduction potentials of different transport sectors under different scenarios in 2020-2060, and finally explored the co-reduction effect for CO₂ and the four pollutants under different control measures. The results showed that the CO₂ emissions from the transportation sectors in the Beijing-Tianjin-Hebei (BTH) region would increase greatly under the baseline scenario. Estimates indicate that the CO₂emissions of Beijing, Tianjin and Hebei Province would increase by 263.72%, 225.87% and 405.43% in 2060, respectively. Under the comprehensive policy scenario, the emission reductions would be 88.78%, 76.86% and 83.20% respectively, and the maximum emission reduction rate of pollutants is expected to reach 78.73%-99.34%. The sectors with major reduction potentials for CO₂ and conventional pollutants are the aviation and road transport sectors, which contribute 38.19%-99.85% of the total, respectively. The co-reduction achieved by optimizing the energy structure in the road transport and aviation sectors would be the best. The results of this study can provide a basis for the formulation of low-carbon reduction strategies for the transport sectors in the BTH region.

Key words: transport sector, reduction potential, scenario analysis, Beijing-Tianjin-Hebei region

GUO Xiurui, GONG Xiaoqian, LIU Yao, ZHANG Yiling. Projections of the Emission Reductions of Carbon Dioxide and Conventional Pollutants in the Major Transport Sectors of the Beijing-Tianjin-Hebei Region, China[J]. Journal of Resources and Ecology, 2023, 14(2): 372-382.

Figures/Tables 9

References 32

[1]	Aggarwal P, Jain S. 2016. Energy demand and CO₂ emissions from urban on-road transport in Delhi: Current and future projections under various policy measures. Journal of Cleaner Production, 128(1): 48-61.
[2]	Aliakbar K, Ali V, Ahmed K B I. 2012. An estimation of traffic related CO₂ emissions from motor vehicles in the capital city of Iran. Iranian Journal of Environmental Health Science & Engineering, 9(1): 9-13.
[3]	Azam M, Othman J, Ara B R, et al. 2016. Energy consumption and emission projection for the road transport sector in Malaysia: An application of the LEAP model. Environment, Development and Sustainability, 18(4): 1027-1047.
[4]	Bu C J, Cui X Q, Li R Y, et al. 2021. Achieving net-zero emissions in China’s passenger transport sector through regionally tailored mitigation strategies. Applied Energy, 284: 116265. DOI: 10.1016/j.apenergy.2020.116265.
[5]	Costa E, Seixas J, Baptista P, et al. 2018. CO₂ emissions and mitigation policies for urban road transportation: Sao Paulo versus Shanghai. Urbe Revista Brasileira de Gestão Urbana, 10(1): 143-158.
[6]	Du L L, Zhao H J, Tang H Y, et al. 2021. Analysis of the synergistic effects of air pollutant emission reduction and carbon emissions at coal-fired power plants in China. Environmental Progress & Sustainable Energy, 40(5): 711-723.
[7]	Fan J L, Wang J X, Li F Y, et al. 2017. Energy demand and greenhouse gas emissions of urban passenger transport in the Internet era: A case study of Beijing. Journal of Cleaner Production, 165: 177-189.
[8]	Feng X Z, Zhao M X, Wang M, et al. 2021. Simulation research on co-controlling pollutants and greenhouse gases emission in China’s transportation sector. Climate Change Research, 17(3): 279-288. (in Chinese)
[9]	Gao Y. 2019. Analysis of traffic carbon emission accounting and influencing factors in Tianjin. Recyclable Resources and Circular Economy, 12(6): 18-21. (in Chinese)
[10]	Guo J X, Zeng Y, Zhu K W, et al. 2021. Vehicle mix evaluation in Beijing’s passenger-car sector: From air pollution control perspective. Science of the Total Environment, 785: 147264. DOI: 10.1016/J.SCITOTENV.2021.147264.
[11]	Guo X R, Liu F X, Fu L W, et al. 2017. Scenarios prediction of energy saving and emission reduction in the road transport sector of Beijing-Tianjin-Hebei region. Journal of Beijing University of Technology, 43(11): 1743-1749. (in Chinese)
[12]	Hong S J, Chung Y H, Kim J, et al. 2016. Analysis on the level of contribution to the national greenhouse gas reduction target in Korean transportation sector using LEAP model. Renewable and Sustainable Energy Reviews, 60: 549-559.
[13]	Huo H, Wang M, Zhang X, et al. 2012. Projection of energy use and greenhouse gas emissions by motor vehicles in China: Policy options and impacts. Energy Policy, 43: 37-48.
[14]	Kazancoglu Y, Ozbiltekin P M, Ozkan-Ozen Y D. 2021. Prediction and evaluation of greenhouse gas emissions for sustainable road transport within Europe. Sustainable Cities and Society, 70: 102924. DOI: 10.1016/J.SCS.2021.102924.
[15]	Li H, Tan X C, Guo J X, et al. 2019. Study on an implementation scheme of synergistic emission reduction of CO₂ and air pollutants in China’s steel industry. Sustainability, 11(2): 352-358.
[16]	Li Y Y, Song Y D. 2021. Study on the synergetic emission reduction effect of CO₂ and air pollutants from the mobile source of urban roads in Beijing under the target of carbon neutralization. Chinese Journal of Environmental Management, 13(3): 113-120. (in Chinese)
[17]	Liu L, Wang K, Wang S S, et al. 2018. Assessing energy consumption, CO₂ and pollutant emissions and health benefits from China’s transport sector through 2050. Energy Policy, 116: 382-396.
[18]	Lu I J, Lewis C, Lin S J. 2009. The forecast of motor vehicle, energy demand and CO₂ emission from Taiwan’s road transportation sector. Energy Policy, 37(8): 2952-2961.
[19]	Lv C, Li Y X, Yang N, et al. 2020. Assessment and scenario analysis of on-road vehicle greenhouse gases emission: A case study of Bejing. Environmental Engineering, 38(11): 25-32. (in Chinese)
[20]	Lv Q. 2018. Study on the driving factors of vehicle transport carbon emissions in Beijing-Tianjin-Hebei region. China Environmental Science, 38(10): 3689-3697. (in Chinese)
[21]	Mao X Q, Xing Y K, Gao Y B, et al. 2021. Study on GHGs and air pollutants co-control: Assessment and planning. China Environmental Science, 41(7): 3390-3398. (in Chinese)
[22]	Nie H W, Deng J, Shi Z Z. 2019. Research on the carbon emission inventory of passenger transportation in Guizhou. Highway, 64(2): 252-255. (in Chinese)
[23]	Ning X J, Zhang J P, Qin Y C, et al. 2014. Spatial and temporal characteristics of carbon emissions from urban resident travel in Zhengzhou. Resources Science, 36(5): 1021-1028. (in Chinese)
[24]	Tan Q L, Yang H W. 2017. Analysis on the synergistic effect of Beijing-Tianjin-Hebei traffic control of greenhouse gases and pollutants. China Energy, 39(4): 25-31. (in Chinese)
[25]	Yang H Z, Liu J F, Jiang K J, et al. 2018. Multi-objective analysis of the co-mitigation of CO₂ and PM_2.5 pollution by China’s iron and steel industry. Journal of Cleaner Production, 185: 331-341.
[26]	Yang L, Wang Y X, Lian Y J, et al. 2020. Factors and scenario analysis of transport carbon dioxide emissions in rapidly-developing cities. Transportation Research Part D, 80(C): 102252. DOI: 10.1016/j.trd.2020.102252.
[27]	Yang W, Song J. 2021. Simulating optimal development of clean coal-fired power generation for collaborative reduction of air pollutant and CO₂ emissions. Sustainable Production and Consumption, 28(10): 811-823.
[28]	Yu Y, Jin Z X, Li J Z, et al. 2020. Low-carbon development path research on China’s power industry based on synergistic emission reduction between CO₂ and air pollutants. Journal of Cleaner Production, 275: 123097. DOI: 10.1016/j.jclepro.2020.123097.
[29]	Yuan Z Y, Li Z Y, Kang L P, et al. 2021. A review of low-carbon measurements and transition pathway of transport sector in China. Climate Change Research, 17(1): 27-35.
[30]	Zhang L X, Li Z W, Jia X P, et al. 2020. Targeting carbon emissions mitigation in the transport sector: A case study in Urumqi, China. Journal of Cleaner Production, 259: 120811. DOI: 10.1016/j.jclepro.2020.120811.
[31]	Zhao B, Wang P, Ma J Z, et al. 2012. A high-resolution emission inventory of primary pollutants for the Huabei region, China. Atmospheric Chemistry and Physics, 12(255): 481-501.
[32]	Zhu C Z, Wang M, Du W B. 2020. Prediction on peak values of carbon dioxide emissions from the Chinese transportation industry based on the SVR Model and scenario analysis. Journal of Advanced Transportation, 2020: 1-14. DOI: 10.1155/2020/8848149.

Sub-sector	Energy type	CO₂	CO	NOx	SO₂	PM_2.5
Highway	Gasoline	2025.28	234.16	17.56	0.58	0.44
	Diesel	2168.69	29.27	23.42	5.41	1.06
	LPG	1861.35	234.16	17.56	0.00	0.01
	CNG	1624.54	11.71	17.58	0.00	0.03
Railway	Diesel	2168.69	29.27	35.12	5.41	0.01
Aviation	Kerosene	2106.84	2.93	8.78	5.83	0.96
Waterway	Fuel oil	2201.98	29.27	43.91	5.83	0.80

Sub-sector	Energy type	CO₂	CO	NOx	SO₂	PM_2.5
Highway	Gasoline	2025.28	234.16	17.56	0.58	0.44
	Diesel	2168.69	29.27	23.42	5.41	1.06
	LPG	1861.35	234.16	17.56	0.00	0.01
	CNG	1624.54	11.71	17.58	0.00	0.03
Railway	Diesel	2168.69	29.27	35.12	5.41	0.01
Aviation	Kerosene	2106.84	2.93	8.78	5.83	0.96
Waterway	Fuel oil	2201.98	29.27	43.91	5.83	0.80

Region	CO₂	NOx	SO₂	PM_2.5
Beijing	615	0.05	0.03	0.01
Tianjin	811	0.06	0.02	0.01
Hebei	903	0.09	0.04	0.01

Region	CO₂	NOx	SO₂	PM_2.5
Beijing	615	0.05	0.03	0.01
Tianjin	811	0.06	0.02	0.01
Hebei	903	0.09	0.04	0.01

Scenario	Scenario definition	Specific description
Transportation Structure Adjustment (TSA)	The proportion of railway transport in the BTH region would be increased, vigorously develop railway freight and waterway freight transport, build a national comprehensive three-dimensional transportation network with railway as the main trunk based on the highway, and make use of the comparative advantages of water transport and civil aviation	In 2060, railway freight would account for 80% in Beijing, 60% railway and 35% waterway freight in Tianjin, and 70% railway and 25% waterway freight in Hebei Province The population of private cars in Beijing, Tianjin and Hebei would be controlled within 5, 4 and 30 million, respectively The sharing rate of passenger public transport in the city would be increased
Energy Efficiency Improvement (EEI)	With the continuous innovation and progress of science and technology, the energy consumption per unit activity level of the terminal equipment in various transportation sectors would decrease; the continuous optimization of fuel economy and the popularization of new technologies would be increasingly extensive in the transport sectors	Energy consumption of highway passenger turnover would decrease by 1.5%, road freight by 1%, air freight by 2%, fuel efficiency of private cars and taxis by 1.5%, and bus fuel efficiency by 1%. Energy consumption of highway passenger and freight traffic would decrease by 1% per year, air passenger and freight by 2% and 1%, fuel efficiency of private taxis by 1%, and bus fuel efficiency by 0.5%
Optimizing the Energy Structure (ESO)	The rate of clean energy consumption in transportation sectors would increase, and the proportion of clean energy sources such as electricity, natural gas, biofuels and hydrogen energy used for all kinds of vehicles would increase	In 2040, all buses and taxis in Beijing would be all electricity-driven; in 2050, road passenger transport and private cars would be all driven by new energies; in 2060, road freight would all be new energy driven; railway electrification would account for 80%, and aviation biofuel would account for 80%. In 2060, new energy used in the road passenger and freight in Tianjin and Hebei Province would account for more than 80%, the electrification of railway passenger and freight would account for 80%, aviation biofuel would account for 70%, clean energy such as biofuel applied in the water transportation industry would account for 60%
